Sturdy design with galvanized metal casing for use in tough environments. Electronically controlled feeding gives accurate and stable arc. The 4-wheel feeder mechanism with grooves in both feed roll and pressure roll gives stable feeding and low wear on the wire, all to avoid operational disturbance.

The feeders are available with either 30 mm diameter rollers for wires 0.6 to 1.6 mm in Steel, Stainless and 0.9 to 1.6 mm in Aluminium.

Choose your level of control. Multiple panel options with U6, U82 and the new MA25 panel specialized for Steel and Aluminium applications.

推薦

• New drive motor offers more torque for improved arc starts, more consistent speed and less noise

• Redesigned drive rolls and feed mechanism for more positive feeding performance and reduced risk of wire shavings

• Short Circuit Termination (SCT) technology sharpens the wire at the end of each weld to promote better arc starts

• Feed 3004 can be equipped with a counter balance arm, lifting eye or a wheel kit for increased mobility

• TrueArcVoltage? system measures the correct arc voltage at the contact tip (together with ESAB torches).

行業(yè)

• 能源

• 移動設(shè)備

• 近海石油

• 軌道車輛

• 船舶/躉船制造

• 鋼鐵工業(yè)

• 交通運輸

• 采礦

• 風塔
